Walk Through Metal Detector (Body temperature measure)

Model: PS-300

Walk through metal detector PS-300 with Body temperature measure
Function, two sensors built on door panels for different high passengers.
Sound and led alarm for metals and high temperature people.
PS-300 walk through scanner adopts advanced DSP technology, auto
calibration and self-testing, multi-zones alarm and five-bit count, it can
work indoor and outdoor. The human body temperature measure result
will display on panel accurately.

Features

• 18 zones setting freely, multi-zones detection alarm separately
• LED digital display with function press keys, 5-bit count on control box
• It is able to detect ferrous and non-ferrous metals
• 1-25s alarm time, 10 level volume and 16 tones for choose
• Automatically count passengers and alarm times
• Self-diagnostic procedures and calibration
• DSP digital technology, Sound alarm, volume adjustable
• Modular structure is easy to do after sales service.
• Harmless to pregnant woman and heart pacemaker
• Tamper-proof, operate program is protected by password
• Password protection for preventing parameter program changed
• No-touch body temperature infrared measure technology
• Temperature accuracy: Imported IR sensor± 0.1° C
• Body temperature measured through forehead/wrist/palm
• 10-30cm detection distance between human and sensor
• Display way is pass count auto and test result display, body high temperature alarm.
• Led alarm bars built in front of door panels that is for accurate detection and alarm display
• Two sensors built on door panels for different high passengers measure

Technical Specification

• Electric current: AC210 – 240V, 50/60Hz
• Power consumption: Max 15W
• Working temperature: -20°C to 60°C
• Outer frame size: 2200mm x 820mm x 460mm
• lnner frame size: 2000mm x 700mm x 450mm
• Control box package size: 2250mm • 650mm * 220mm
• Door panel package size: 752mm • 405mm • 251mm
• Gross weight: 65 Kg

Applications
